Action replay of powerful stellar explosion

A new way of studying supernovae has been found by observing both remnants and light echoes.Provided by the Chandra X-ray Center, Cambridge, Massachusetts
By | Published: March 21, 2008 | Last updated on May 18, 2023

supernova remnant 0509-67.5
A panoramic view of the Large Magellanic Cloud shows the location of the supernova remnant 0509-67.5 and a light echo that was generated when the massive progenitor star exploded.
NOAO/AURA/NSF
March 21, 2008
Astronomers have made the best ever determination of the power of a supernova explosion that was visible from Earth long ago. By observing the remnant of a supernova and a light echo from the initial outburst, they have established the validity of a powerful new method for studying supernovas.

Using data from NASA’s Chandra X-ray Observatory, ESA’s XMM-Newton Observatory, and the Gemini Observatory, two teams of researchers studied the supernova remnant and the supernova light echo that are located in the Large Magellanic Cloud (LMC), a small galaxy about 160,000 light-years from Earth. They concluded that the supernova occurred about 400 years ago (in Earth’s time frame), and was unusually bright and energetic.

This result is the first time two methods&#8212X-ray observations of a supernova remnant and optical observations of the expanding light echoes from the explosion&#8212have both been used to estimate the energy of a supernova explosion. Up until now, scientists had only made such an estimate using the light seen soon after a star exploded, or using remnants that are several hundred years old, but not from both.

supernova remnant 0509-67.5
This Chandra’s image shows the circular shape of the remnant detected in X-ray light.
NASA/CXC/Rutgers Optical
“People didn’t have advanced telescopes to study supernovae when they went off hundreds of years ago,” says Armin Rest of Harvard University, who led the light echo observations using Gemini. “But we’ve done the next best thing by looking around the site of the explosion and constructing an action replay of it.”

In 2004, scientists used Chandra to determine that a supernova remnant, known as SNR 0509-67.5 in the LMC, was a so-called Type Ia supernova, caused by a white dwarf star in a binary system that reaches a critical mass and explodes.

In the new optical study, an estimate of the explosion’s energy came from studying an echo of the original light of the explosion. Just as sound bounces off walls of a canyon, so too can light waves create an echo by bouncing off dust clouds in space. The light from these echoes travels a longer path than the light that travels straight toward us, and so can be seen hundreds of years after the supernova itself.

First seen by the Cerro-Tololo Inter-American Observatory in Chile, the light echoes were observed in greater detail by Gemini Observatory in Chile. The optical spectra of the light echo were used to confirm that the supernova was a Type Ia and to unambiguously determine the particular class of explosion and therefore its energy.

The Chandra data, along with XMM-Newton data obtained in 2000, were then independently used to calculate the amount of energy involved in the original explosion, using an analysis of the supernova remnant and state-of-the-art explosion models. Their conclusion confirmed the results from the optical data, namely that the explosion was an especially energetic and bright variety of Type Ia supernovae. This agreement provides strong evidence that the detailed explosion models are accurate.

light echo
Optical data from ground-based telescopes show this light echo traveling through space. This result marks the first time researchers combined two separate methods to estimate the energy of a supernova explosion.
NOAO/AURA/NSF
“Having these two methods agree lets us breathe a sigh of relief,” says Carlos Badenes of Princeton University who led the Chandra and XMM-Newton study. “It looks like we’re on the right track with trying to understand these big explosions. Their stellar debris really can retain a memory of what created them hundreds of years earlier.”

Both methods estimated a similar time since the explosion of about 400 years. An extra constraint on the age comes from the lack of recorded historical evidence for a recent supernova in the LMC. Because this star appears in the southern hemisphere, it likely would have been seen by navigators who noted similarly bright celestial events if it had occurred less than about 400 years ago.

Because Type Ia supernovae have nearly uniform intrinsic brightness, they are used as important tools by scientists to study the expansion of the universe and the nature of dark energy.

“It’s crucial to know that the basic assumptions about these explosions are correct, so they’re not used just as black-boxes to measure distances,” says Badenes.

This work is also being extended to other supernovae remnants and light echoes.

“This is the first case where the conclusions that are drawn from the supernova remnant about the original explosion can be directly tested by looking at the original event itself,” says Rest. “We’ll be able to learn a lot about supernovas in our own galaxy by using this technique.”
