“This latest image is another demonstration of the invaluable assistance the MRO team, and its sister team with the Mars Odyssey orbiter, have provided the Curiosity rover during our early days on the Red Planet,” said Mike Watkins from NASA’s Jet Propulsion Laboratory (JPL) in Pasadena, California. “The image not only satisfies our curiosity, but also can provide important information on how these vital components performed during entry, descent, and landing, and exactly locate the rover’s touchdown site within Gale Crater.”
The Curiosity rover is in the center of the image. To the right, approximately 4,900 feet (1,500 meters) away, lies the heat shield, which protected the rover from the 3800° Fahrenheit (2100° Celsius) temperatures it encountered during its fiery descent. On the lower left, about 2,020 feet (615m) away, are the parachute and back shell. The parachute has a constructed diameter of 71 feet (21.5m) and an inflated diameter of 51 feet (16m). The back shell remains connected to the chute via 80 suspension lines that are 165 feet (50m) long. To the upper left, approximately 2,100 feet (650m) away from the rover, is a discoloration of the Mars surface consistent with what would have resulted when the rocket-powered Sky Crane impacted the surface.
“This is the first of what I imagine will be many portraits HiRISE will be taking of Curiosity on the surface of Mars,” said Sarah Milkovich from JPL. “The image was taken Monday at about 10:30 p.m. Pacific when MRO was at an altitude of about 186 miles (300 kilometers), and we are getting resolution on the surface down to 1.3 feet (39 centimeters) per pixel.”
As more of Curiosity’s instruments are coming online, more “first images” are being downlinked from the rover’s 17 cameras. The latest to come in is from the Mars Hand Lens Imager (MAHLI). The focusable color camera is located on the tool-bearing turret at the end of Curiosity’s robotic arm. Researchers will use it for magnified, close-up views of rocks and soils and also for wider scenes of the ground, the landscape, or even the rover.
“It is great to have our first MAHLI image under our belt,” said Ken Edgett from Malin Space Science Systems in San Diego. “We tested the focus mechanism and imager, and the whole system is looking good. We are looking forward to getting up close and personal with Mars.”
The team plans for Curiosity checkout Tuesday included raising the rover’s mast and continued testing of the high-gain antenna.
Curiosity carries 10 science instruments with a total mass 15 times as large as the science payloads on the Mars rovers Spirit and Opportunity. Some of the tools, such as a laser-firing instrument for checking rocks’ elemental composition from a distance, are the first of their kind on Mars. Curiosity will use a drill and scoop, which is located at the end of its robotic arm, to gather soil and powdered samples of rock interiors, then sieve and parcel out these samples into the rover’s analytical laboratory instruments.
To handle this science toolkit, Curiosity is twice as long and five times as heavy as Spirit or Opportunity. The Gale Crater landing site places the rover within driving distance of layers of the crater’s interior mountain. Observations from orbit have identified clay and sulfate minerals in the lower layers, indicating a wet history.
